Shutter Roll Forming Machine

Name: Shutter Roll Forming Machine
Brand: Sensitive Engitech Pvt. Ltd.
Price: 2900000.0 INR
Availability: InStock

Price 2900000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Shutter Roll Forming Machine Specification

Type
Shutter Roll Forming Machine

Material
Mild Steel

Capacity
10-15 m/min

Computerized
Yes

Automatic Grade
Automatic

Control System
PLC Control

Rolling Speed
10-15 m/min

Cutting System
Hydraulic Cutting

Cutting Thickness
0.3-1.2 mm

Voltage
380V/50Hz/3Phase

Color
Blue/Grey

Dimension (L*W*H)
6000 mm x 1000 mm x 1200 mm

Weight
About 3.5 Tons

Feeding Width
Up to 300 mm

Drive Type
Chain Drive

Application
Rolling Shutter Slats/Forming

Transmission Type
Gear/Chain

Working Temperature
5C to 40C

Power
7.5 kW

Number of Forming Stations
16-18

Roller Material
High Grade Steel with Hard Chrome Coating

After Sales Service
Available

Operator Interface
Touchscreen HMI

Shutter Roll Forming Machine Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1

About Shutter Roll Forming Machine

Shutter Roll Forming Machine
Our Shutter Roll Forming Machine is designed for the efficient production of high-quality rolling shutter profiles, door slats, and metal shutter components with excellent precision. Manufactured using advanced roll forming technology, this machine ensures smooth finishing, accurate shaping, and consistent output for industrial and commercial applications. It is ideal for producing durable shutter sections used in shops, warehouses, garages, and security doors. With robust construction, easy operation, low maintenance, and high production efficiency, the Shutter Roll Forming Machine delivers reliable performance and long service life.

Key Features:

High-precision roll forming process
Suitable for rolling shutter slats and profiles
Smooth finishing and accurate shaping
Strong and durable machine structure
Easy operation and low maintenance
High production efficiency
Reliable and consistent performance
Ideal for industrial and commercial applications
Long service life and heavy-duty design

Advanced Automation and Precision

Equipped with a PLC control system and touchscreen HMI, the machine simplifies operation while enhancing accuracy in shutter slat formation. Its automated functionalities minimize human intervention, ensuring each forming and cutting cycle delivers consistent output. This level of precision is complemented by the reliable hydraulic cutting mechanism that handles varied steel thicknesses effortlessly.

Robust Build for Industrial Demands

Built with high-grade steel rollers coated in hard chrome, the machine offers exceptional durability for heavy-duty workflows. With a chain and gear transmission, it maintains steady performance even during intensive production cycles. The system's compact dimensions and 3.5-ton weight make it suitable for most factory floors without compromising stability or longevity.

FAQ's of Shutter Roll Forming Machine:

Q: How does the Shutter Roll Forming Machine ensure accurate shutter slat production?

A: The machine uses precision-engineered rollers made from high-grade steel with hard chrome coating and is controlled via a PLC system with touchscreen HMI. These features guarantee consistent forming and cutting accuracy across all produced slats.

Q: What materials and thicknesses can the machine process?

A: It is designed for mild steel with thicknesses ranging from 0.3 mm to 1.2 mm, making it suitable for robust and lightweight shutter applications.

Q: When is after-sales support available for this machine?

A: After-sales service is readily available upon installation and throughout the operational life of the machine, ensuring users have access to timely technical support and maintenance.

Q: Where can this machine be effectively used?

A: This shutter roll forming machine is best suited for manufacturing sites or industrial settings involved in rolling shutter slat production, thanks to its dimensions and automatic grade.

Q: How does the feeding and transmission process work?

A: Material is loaded up to a 300 mm width, then conveyed through 16-18 forming stations using a robust gear and chain-driven system, optimizing precision and efficiency at speeds of 10-15 meters per minute.

Q: What are the main benefits of using this machine for shutter production?

A: Key benefits include increased production efficiency, reduced manual labor, superior build quality of slats, and reliable operation supported by automated control and a durable, heavy-duty build.
