Solar Structure Roll Forming Machine

Name: Solar Structure Roll Forming Machine
Brand: Sensitive Engitech Pvt. Ltd.
Price: 2900000.0 INR
Availability: InStock

Price 2900000.0 INR/ Unit

Get a Price/Quote

MOQ : 1 Unit

Solar Structure Roll Forming Machine Specification

Type
Solar Structure Roll Forming Machine

Material
Mild Steel

Capacity
8-15 m/min (rolling speed)

Computerized
Yes

Automatic Grade
Automatic

Rolling Speed
8-15 m/min

Cutting System
Hydraulic Cutting

Cutting Thickness
1.2-2.5 mm

Voltage
380V/50Hz/3Phase

Color
Blue and Yellow

Dimension (L*W*H)
8000 mm x 1500 mm x 1400 mm

Weight
6-8 Tons

Roller Stations
18-24 stations (approx)

Production Line
Single/Double out

Profile Width
Up to 350 mm

Transmission System
Gearbox + Chain

Usage
Industrial

Feeding Method
Automatic Feeding

Drive Type
Gear/Chain Drive

Noise Level
85 dB

Roller Material
High Grade Steel with Hard Chrome Plating

Operating System
Button Control + Touch screen interface

Main Motor Power
11-15 kw

Hydraulic Power
5.5 kw

Application
Solar Mounting Structure Channel Fabrication

Cutting Length Tolerance
2 mm

Solar Structure Roll Forming Machine Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1

About Solar Structure Roll Forming Machine

Solar Roll Forming Machine
Our Solar Roll Forming Machine is designed for high-precision manufacturing of solar panel mounting structures, channels, and profiles. Built with advanced technology, this machine ensures accurate shaping, smooth finishing, and high production efficiency. It is widely used in the solar energy industry for producing durable and reliable components with excellent strength. Easy to operate, low maintenance, and highly efficient, the Solar Roll Forming Machine is ideal for large-scale industrial production and customized profile requirements.

Key Features:

High-speed and accurate roll forming process
Strong and durable machine structure
Low maintenance and easy operation
Suitable for solar mounting channels and profiles
High production efficiency
Reliable performance with long service life

Precision and Efficiency in Solar Channel Fabrication

This roll forming machine integrates top-tier automation and control, allowing for swift production of solar mounting structure channels. Its computerized PLC system ensures accuracy in every operation, while the automatic feeding mechanism optimizes workflow efficiency. Operators can seamlessly adjust production parameters via button control or touch screen, streamlining channel manufacturing for solar installations.

Robust Construction and Performance

Built from mild steel and fitted with hard chrome-plated, high-grade steel rollers, the machine is designed for long-term durability and reliable performance. A high-powered main motor, along with a combination gearbox and chain transmission, provides consistent output at speeds of 8-15 meters per minute. The sturdy blue and yellow frame houses advanced hydraulic cutting for exacting profiles.

FAQ's of Solar Structure Roll Forming Machine:

Q: How does the automatic feeding system work in this solar structure roll forming machine?

A: The automatic feeding system utilizes sensors and a precision control module to continuously supply raw material into the rollers, ensuring smooth, uninterrupted production with minimal manual intervention.

Q: What types of profiles can be produced with this machine?

A: This roll forming machine is designed to fabricate solar mounting structure channels with profile widths up to 350 mm and thicknesses ranging from 1.2 to 2.5 mm, meeting various solar installation requirements.

Q: Where is this machine most effectively used?

A: The machine is ideal for industrial applications, particularly in manufacturing facilities focused on producing solar mounting structure channels for solar panel installations and renewable energy projects.

Q: What benefits does gear and chain drive bring to production?

A: The combination of gear and chain drive systems optimizes torque transmission, reduces mechanical slippage, and enhances the machine's overall stability and operational lifespan.

Q: How accurate is the cutting process on this roll forming line?

A: Featuring hydraulic cutting with a length tolerance of 2 mm, the machine ensures highly accurate and consistent channel sizes, essential for reliable assembly in solar mounting systems.

Q: What control options are available for machine operation?

A: Operators can select between a conventional button control panel and a modern touch screen interface, both integrated with a computerized PLC system for straightforward, flexible, and safe machine management.
